High-performance Graphite Packing featuring PTFE lubrication and reinforced Aramid corners for demanding pump and valve sealing in industrial applications. Available wholesale.
Features diagonally braided construction combining graphite-filled PTFE yarns and robust Aramid fiber corners.
Provides excellent thermal conductivity and heat dissipation due to graphite content.
Offers low friction sealing suitable for high-speed rotating equipment and valve stems.
Aramid reinforced corners enhance extrusion resistance and durability, especially in abrasive conditions.
Delivers superior sealing performance across a wide range of industrial chemicals and pressures.
Combines the chemical resistance of PTFE, lubricity of graphite, and strength of Aramid.
Ideal for demanding pump, valve, mixer, and agitator sealing in chemical, petrochemical, and paper industries.
Material Composition: Braided Graphite-Filled PTFE Yarn with Aramid Fiber Corners
Temperature Range: -100°C to +280°C
Max Pressure (Static): Approx. 250 Bar
Max Pressure (Rotating): Approx. 30 Bar
Max Shaft Speed: Approx. 15-20 m/s
pH Range: 2-13
